Quick Details

  • Place of Origin: Fujian, China (Mainland)
  • Brand Name: Singflo
  • Model Number: FL Series High Flow
  • Theory: Reciprocating Pump
  • Structure: Diaphragm Pump
  • Usage: Water
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: Electric Power
  • Pressure: Low Pressure
  • Application: Boat,RV,Machine,caravan,home use
  • Characteristic: High Flow
  • Duty cycle: Working intermittent
  • Housing: PA66
  • Valve made: EPDM
  • Liquid temperature: 0-60 ℃
  • Certificate: Rohs/CE/ISO9001:2000/TUV
  • Pump design: 4 chamber diahpragm
  • Max flow: 17LPM
  • Max pressure: 60psi
  • Liquid temp.: within 60 degree.

Packaging & Delivery

Packaging Details with strong seaworthy carton,inner with poly foam
Delivery Time Shipped in 7 days after payment

Singflo hot sale FL-40 17LPM 40PSI 12v high flow water pump/high flow electric water pump/ electric diaphragm pump



Product Description



Type: 4 Chamber Diaphragm
Port Size:  1/2''(12.5mm)House Barb
Liquid:  140°F [60 °C] Max
Self-priming:  6 feet [about 2M]
Max pressure  40psi(2.76bar);can be adjust to 60psi.
Run Dry:  Yes
Motor:
Permanent Magnet, Intermittent
Duty Protection:  Thermal Overload, Automatic Restart
Volts: 12/24 VDC and 115/220 VAC motors standard (consult factory for other voltages)

Features:

  • Lightweight and made from non corroding materials
  • Self priming
  • Run dry Protection
  • Easy to install
  • No maintenance
  • Simple to operate
  • Low power consumption
  • 12 months warranty
  • Automatically turns on and off
  • Comes with filter and fittings

 Technical Data:



TECHNICAL DATA OF DC VOLTAGE
ModelVoltFlow(L/Min)Pressure(PSI)Amp Draw(A)
FL-301210172.2
FL-312410171.5
FL-351212.5357
FL-342412.5354
FL-401217409.2
FL-442417405.6
TECHNICAL DATA OF AC VOLTAGE
ModelVoltFLow(L/Min)Pressure(PSI)Amp Draw(A)
FL-3311512.5350.5
FL-3222012.5350.4
FL-4111517400.5
FL-4322017400.8
Inlets size:1/2''hose barb, thread
Outlets size:1/2''hose barb, thread
dimension/pc FL-3:33.5x12.5x10.5cm
Net weight/pc FL-3:1.9kg
Gross weight/pc FL-3:2.3kg
Carton dimension(10pcs FL-3 Series):63x29x22.5cm
dimension/pc FL-4:37x12.5x10.5cm
Net weight/pc Shape FL-4:2.45kg
Gross weight/pc FL-4:2.9kg
Carton dimension(10pcs FL-4 Series):64x39x22cm











Product Pictures



  Each valve chamber has a diaphragm behind it in the lower pump housing. As the motor shaft turns,

an internal cam positioned behind the diaphragms causes the  diaphragms to be pushed forward, then

back in a continuous sequence creating a suction. As this suction builds, fluid is pulled  hrough the inlet,

through the various valve chamber check valves to the outlet he volume of flow is determined by several

factors including: the number and size of the pump chambers,cam offset, operating pressure, fluid viscosity.
